Conditioning Heat Exchanger Marine Engine Exchanger for Water Cooling System

Quantity:
  • Zhejiang, China
  • 1PC
  • WH
  • ISO9001:2008
  • WHT-GU
  • Negotiation
  • Wooden case
  • 8 working days
  • L/C, T/T, Western Union
  • 100/pcs per month
Product Name: Shell And Tube Evaporator Warranty: 12 Months
Structure: Tube Heat Exchanger Outer Shell: Stainless Steel
Is-customized: Yes Weight: 75KG


Conditioning Heat Exchanger Marine Engine Exchanger for Water Cooling System


Work Condition:



1. Refrigerant side(In the tube): R22,R134a,R407c,R410a etc.
2. Water side (Between the tube and shell):Nature water,drink water,seawater etc .




Special Use: Cooling, Evaporator

Net Weight: Customizable



Application: For seawater,saltwater,brine water etc. cooling .



Working Condition

Evaporator Shell Side Tube Side
 Design Pressure (Mpa)  0.4  1.4
 Max. Pressure (Mpa)  0.4  1.4
 Test Pressure (Mpa)  0.5  1.61
 Design Temperature (C)  38  38
 Medium  Seawater  R22/R404A









Product Name: Shell And Tube Heat Exchanger Voltage: 220V/50Hz
Model Number: WHT-GU System: Single /double/Triple System
Shell Side: Water/salt Water Power: Optional


Water Cooled Evaporator Shell and Tube Heat Exchanger Tubular Heat Exchanger Price





Model: WHT-2GU86

Description:



  • Model: WHT-GU

  • Cooling Capacity: 15kw~900kw

  • Materials: Carbon Steel Shell + Copper Tube

  • Special Use: Cooling, Evaporator

Product Details:



Product Name Shell and Tube Heat Exchanger
Application Heating and Cooling
Feature Corrosion Resistant
Shell Side Water/Salt Water
System Single/Double/Triple System
Tube Plate Titanium
Nuts Stainless Steel
Tube Material TA1 Pure Titannium
Other Shell  PP Plastic/Titanium/Stainless
Is-customized Yes
Product Keywaords Refrigeration Heat Exchanger copper

Application:



  • Shell and tube evaporator is widely used for freezing industries,such as plating ,oxidation ,chemical industry,metallurgy,light industry,shipbuilding,heating, pharmaceutical,foodstuff etc, also for leather chiller, injection molding machine chiller, print chiller,PV shoe machine chiller and so on.



Catalogue:

1.0HP=2.3KW

1.0 Refrigeration Ton = 3.5KW

Titanium Shell And Tube Water Cooled Condenser , Tubular Heat Exchanger 15kw - 900kw



Model Capacity Water Flow Dimension(MM)
HP M3/H A B C D E F G H L L1 T1 T2
WHT-2GU28 5+5 4.8 1060 850 140 168 280 600 60 290 200 150 35 35
WHT-2GU35 6+6 6.0 1300 1080 145 168 300 800 60 290 200 150 35 35
WHT-2GU45 8+8 7.7 1145 930 145 195 185 800 60 315 200 150 40 40
WHT-2GU55 10+10 9.5 1310 1080 150 195 300 800 60 325 200 150 40 40
WHT-2GU65 12+12 11.2 1510 1280 150 195 300 1000 60 325 200 150 40 40
WHT-2GU86 15+15 14.8 1670 1410 166 219 380 1000 80 369 250 200 45 45
WHT-2GU120 20+20 20.6 1690 1400 191 245 280 1200 80 419 250 200 55 55
WHT-2GU135 25+25 23.2 1840 1540 191 245 350 1200 80 419 250 200 55 55
WHT-2GU210 40+40 36.1 2250 1950 191 273 450 1500 80 451 300 250 65 65

 About us



Titanium Shell And Tube Water Cooled Condenser , Tubular Heat Exchanger 15kw - 900kw



1. Are you factory?

Yes,we are one of the largest corrosion resistant heat exchanger manufactory in China




2. Are there any discount for the heat exchangers?

Yes. Bigger quantity will enjoy lower discount!




3. What information needed if I want a quotation?

Please advise us the Type of heat exchangers, Material , Heat Exchanger Capacity, Water Flow, Water Temperature in and out ,Refrigrant Freon Type, Quantity, or any requirements in size.




4. What is the MOQ?

We accept loose quantity order,mixed order,any trial orders.




5. When can I get the price?

We usually quote within 8 hours after we get your inquiry.
