| Quantity: | |
|---|---|
| Product Name: | Swimming Pool Heat Exchanger | Condition: | New |
|---|---|---|---|
| Model Number: | WHC-DRL | Feature: | Anti-corrosion |
| Warranty: | 12 Months | Is-Customized: | Yes |
Clean Easily Swimming Pool Heat Exchanger Swimming Spa Heat Exchanger from Water to Air Evaporator
Model: WHC-15.0SRL
Heating Capacity: 45KW
Cooling Capacity: 34.5KW
Materials: PP Shell + Pure Titanium Tube
Special Use: Heating, as condenser
| Connection (mm) | ||||
| Model | Refrigerant Side | Water Side | ||
| Inlet | Outlet | Inlet | Outlet | |
| WHC-0.5DRL | 12.7 | 12.7 | OD32 | OD32 |
| WHC-1.0DRL | 12.7 | 12.7 | OD32 | OD32 |
| WHC-1.5DRL | 12.7 | 12.7 | OD32 | OD32 |
| WHC-2.0DRL | 12.7 | 12.7 | OD32 | OD32 |
| WHC-3.0DRL | 12.7 | 19.0 | OD50 | OD50 |
| WHC-5.0DRL | 12.7 | 19.0 | OD50 | OD50 |
| WHC-6.0DRL | 12.7 | 19.0 | OD50 | OD50 |
| WHC-8.0ERL | 12.7 | 19.0 | OD50 | OD50 |
| WHC-10.0ERL | 12.7 | 19.0 | OD63 | OD63 |
| WHC-12.0ERL | 12.7 | 19.0 | OD63 | OD63 |
| WHC-15.0SRL | 12.7 | 19.0 | OD63 | OD63 |
| WHC-20.0SRL | 12.7 | 19.0 | OD63 | OD63 |
Working Condition:
| Refrigerant side (in tube) | Water side (in the shell) | |
| Design pressure (Mpa) | 4.5 | 0.4 |
| TEMP . Range (°C) | / | -10 to +45℃ |
| Medium | R22/R407C/R134a/R410a etc . | Sea water, salt water, ground water , swimming pool water , etc |
| Notice | 1.Please purge air thoroughly from water system , and cannot exceed the maximum pressure . 2.Keep water quality clean ,suggest to add filters, and regular cleaning . | |
Packaging & Delivery :
* Plywood case
* High compressive strength
* High load-bearing performance
* For the sample order: we used International Express freight: Such as: DHL, TNT, EMS, UPS and
so on
* If your quantity is large, we will consider the Air or Sea Transport, all the detail terms we will discuss
in the Contract
Company Information:
Wenzhou Wuhuan Refrigeration Accessories Factory designs and manufactures a wide
range of heat exchangers for refrigeration, industrial and special applications .
Our evaporators and condensers can be manufactured with different materials and can
work with all types of fluids and with duty up to 6000 kW.
We are prepared for the solution of different heat exchange problems, thanks to the widest
experience of technical departments able to suggest technical solutions best suited to each
customer's need .
Q1. Are you factory?
A. Yes,we are one of the largest corrosion resistant heat exchanger manufactory in China
Q2. May i get your product catalogue?
A. Sure, you are welcome to download the latest catalogue at our web or contact us directly.
Q3. Are there any discount for the heat exchangers?
A. Yes. Bigger quantity will enjoy lower discount!
Q4. What information needed if I want a quotation?
A . Please advise us the Type of heat exchangers, Material , Heat Exchanger Capacity, Water Flow, Water Temperature in and out ,Refrigrant Freon Type, Quantity, or any requirements in size.
