Corrosion Proof Titanium Heat Exchanger , Air Conditioning Immersion Evaporator Coil

Quantity:
  • Zhejiang, China
  • WH
  • ISO9001:2008
  • WHC-DG
  • 1 PC
  • Negotiation
  • Carton
  • 8 - 10 work days after receving the deposit
  • Western Union, L/C, T/T
  • 10000/ Month
Product Name: Titanium Heat Exchanger Coil Warranty: 1 Year
Condition: New Type: Immersion Coil
Tube Size: 19mm(3/4") Materials: Titanium

Product Information:



Titanium Evaporator Titanium Heat Exchanger Air Conditioning Evaporator Coils

Corrosion Proof Titanium Heat Exchanger , Air Conditioning Immersion Evaporator Coil

Features:

  • Usually used for heating and cooling.
  • Pure titanium tube has super strong corrosion proof ability and high intensity.
  • The seamless titanium tube was tested by 2.0MPa pressure to make sure the tube is strong and not leakage .
  • It has the character of strong corrosion resistance ,good heat resistance , high conductivity, non-toxic,no-scale ,no-blocking , no contamination of medium,and not easy to formed oxides on the surface.



Application:

  • Titanium heat exchangers are widely used for mariculture ,seawater heat transfer,saline heat transfer, chemical industry,food Industry,Metallurgy,refrigeration,light industry,plating industry,aluminum oxidation tank,salt manufacturing ,paper making,ultrasonic,electrommunication and central heating etc.

Catalogue:



Model Heat capacity Diameter Quantity Freon inlet/outlet External Dimensions
  kw d e a2 a1 A B C
WHC-1.0DG 2 ∅19.05 6.5 ∅12.7 ∅12.7 375 165 ∅150mm
∅16.0 ∅12.7 ∅12.7 375 165 ∅150mm
WHC-1.5DG 3 ∅19.05 8.5 ∅12.7 ∅12.7 375 240 ∅150mm
∅16.0 ∅12.7 ∅12.7 375 240 ∅150mm
WHC-2.0DG 4 ∅19.05 10.5 ∅12.7 ∅12.7 375 305 ∅150mm
∅16.0 ∅12.7 ∅12.7 375 305 ∅150mm
WHC-3.0DG 6 ∅19.05 13.5 ∅12.7 ∅19.05 375 475 ∅150mm
∅16.0 ∅12.7 ∅16.0 375 475 ∅150mm
WHC-5.0DG 10 ∅19.05 18.5 ∅12.7 ∅19.05 375 645 ∅150mm
∅16.0 ∅12.7 ∅16.0 375 645 ∅150mm




Corrosion Proof Titanium Heat Exchanger , Air Conditioning Immersion Evaporator Coil





Notice:

  • The data list is our suggested data, We can produce any capacity heat exchangers according to customers' requirement and design.
  • To guaranteen improvement of technology , technical parameters shall be improved without further notice.


Packaging & Delivery :



Corrosion Proof Titanium Heat Exchanger , Air Conditioning Immersion Evaporator Coil

* Plywood case
* High compressive strength
* High load-bearing performance
* For the sample order: we used International Express freight: Such as: DHL, TNT, EMS, UPS and
  so on
* If your quantity is large, we will consider the Air or Sea Transport, all the detail terms we will discuss
  in the Contract
